Metcal - CV-5200 Connection Validation Soldering Station

Turn an intelligent guess into a validated "yes" with the evolutionary Metcal CV-5200 Connection Validation Soldering Station.

Frustrated with cold joints, too much solder or insufficient wetting? Now it's easy to verify solder joint reliability. Metcal's CV-5200 Connection Validation Soldering Station goes beyond visual inspection and gives you the "green light" you've always wanted.

With the CV-5200, Metcal introduces technology that will forever change hand soldering. Now see real-time, closed-loop feedback of an intermetallic compound formation (IMC)—a critical component of a successful solder joint. Once the IMC is calculated, if the LED light encircling the handpiece turns green, you'll know you've made a quality solder joint connection.

Added Benefits

  • Helps mitigate the risk of inadequate solder joints; saves money
  • Increases process control for zero tolerance industries, e.g. aerospace, automotive, etc.
  • Complements operator skill with a repeatable, measurable solder process standard
  • Clearly displays tip temperature on large, color graphics screen
  • Provides bidirectional communication from cartridge to power supply using patented chip and cartridge technology
  • Instantly delivers power on demand using SmartHeat®; no calibration needed
  • Chip-in-Cartridge offers
    • Recording and storing of cartridge data for analysis
    • Power supply stability against incorrect cartridges
    • Backward compatibility with MX Series power supplies
  • Password protection

Have questions or like to see a demo?

Contact Us to Find Out More

Introduced at IPC APEX 2017, Metcal's exciting patented technology was met enthusiastically by contract manufacturers and electronics assembly leaders worldwide.

Improve Quality & Mitigates Risk - Reduces solder joint defects by validating the intermetallic compound (IMC) formation in a soldered joint.

Enhance Process Control - The LED light ring integrated in the hand piece notifies the operator of a successful solder joint - complementing the visual industry inspection standard - adding repeatability and a measurable standard to the soldering process.

Improve Compliance - Chip-in-Cartridge technology precisely calculates and displays tip temperature on a large color display, improving audit compliance.

Future-Proof Investment - Communication port provides access to process traceability data and easy firmware upgrades.
