ALPHA NP575-KAP Solder Paste, Sn96.5Ag3.0Cu0.5, 600g Cartridge

Hisco #:275498-1998

MFG #:275498

This item is NEW to our website.
Our Price: $159.92 Cartridge-CQ
Manufacturer Lead Time When Not In Stock21 days
Minimum Order QTY: 10
Item must be ordered in multiples of 10
QuantityPriceSave
30155.23Save 3%

The Kester 275498

Kester's NP575-KAP is a next-generation, high-performance, zero-halogen, lead-free, no-clean solder paste designed for reliability across various applications such as automotive and aerospace. With wide print windows down to area ratios >0.60 and consistent transfer efficiencies on fine feature apertures, it ensures high first-pass yield. It boasts excellent coalescence down to 170 µm circle and square apertures, achieving CpK values >2.0 and transfer efficiencies between 60% and 120% at area ratios. Additionally, it demonstrates outstanding electrochemical performance, meets IPC J-STD-004B ROL0 classification, and is pin-testable. NP575-KAP stands out as Kester's top no-clean paste, part of our high-performance product range.

Kester 275498 Features:
  • Zero-halogen
  • Wide process window and consistent print performance to 0.6AR
  • Excellent reflow and coalescence using both ramp and soak profiles
  • Excellent pin testability
  • Excellent electrochemical reliability

Product Description

The Kester 275498

Kester's NP575-KAP is a next-generation, high-performance, zero-halogen, lead-free, no-clean solder paste designed for reliability across various applications such as automotive and aerospace. With wide print windows down to area ratios >0.60 and consistent transfer efficiencies on fine feature apertures, it ensures high first-pass yield. It boasts excellent coalescence down to 170 µm circle and square apertures, achieving CpK values >2.0 and transfer efficiencies between 60% and 120% at area ratios. Additionally, it demonstrates outstanding electrochemical performance, meets IPC J-STD-004B ROL0 classification, and is pin-testable. NP575-KAP stands out as Kester's top no-clean paste, part of our high-performance product range.

Kester 275498 Features:
  • Zero-halogen
  • Wide process window and consistent print performance to 0.6AR
  • Excellent reflow and coalescence using both ramp and soak profiles
  • Excellent pin testability
  • Excellent electrochemical reliability

Technical Information

BrandKester
Our Price: $159.92 Cartridge-CQ

Minimum Order QTY: 10
Item must be ordered in multiples of 10
