3M™ Adhesive Transfer Tape 9506, Clear, 24 in x 180 yd, 5 mil, Flag splices, 1 roll per case, Restricted

3M™ Adhesive Transfer Tape 9506 features 3M™ High Performance Acrylic Adhesive 200MP, the industry standard for graphic attachment and die-cut parts. This 5 mil clear adhesive offers excellent shear strength, minimal edge lifting and reduced slippage on medium- to high-surface energy plastics. A 58# PCK liner provides excellent adhesive coverage and adds dimensional stability.

A Powerful, Economical Choice for General Industrial Joining
Featuring 3M™ High Performance Acrylic Adhesive 200MP – the industry standard for graphic attachments – our 3M™ Adhesive Transfer Tape 9506 is tough, transparent and delivers shear strength that resists slippage and edge lifting. With excellent high temperature and UV resistance and some repositionability, it is ideal for graphic and nameplate attachment as well as membrane switch bonding. Tape is protected by a 58# polycoated kraft paper liner suitable for most die-cutting operations.

3M™ Adhesive Transfer Tape 9506 is suitable for a variety of general industrial applications, and is available in custom sizes.

Recommended Applications


General industrial joining applications
Graphic overlays and attachment
Laminating PC, ABS and PET
Bonding nameplates
Signage attachment
Bonding membrane switches


About Our High Performance Acrylic Adhesive 200MP
3M™ High Performance Acrylic Adhesive 200MP is an industry standard for graphic attachment and general industrial joining applications. It features outstanding adhesion to metal, polycarbonate (PC), ABS and polyester (PET), making it a popular choice across many industries. This adhesive provides some initial repositionability for placement accuracy when bonding to plastics. It also performs well after exposure to humidity and hot/cold cycles, providing confidence that the switch will perform through difficult environmental conditions and millions of actuations.

What are Adhesive Transfer Tapes?
In general, 3M adhesive transfer tapes are rolls of pressure sensitive adhesive pre-applied to a special release liner. The tape consists of adhesive only, and does not have any type of carrier material such as film or paper. For application the tape is positioned adhesive side down to a surface and the liner is removed, exposing the backside adhesive to the joining surface.

Better Science for Better Adhesives from 3M
Since 1925 when one of our lab assistants invented masking tape, 3M has been applying science to life – developing adhesive products and technologies that help entire industries and individual businesses worldwide. The work that began with a single 3M engineer now spans decades and generations. And all of it goes into each of our industrial labeling and adhesive products like 3M™ Adhesive Transfer Tape 9506, to help businesses like yours operate faster, better and more efficiently.

• Excellent for economical graphic attachment and general industrial joining
• Adhesive 200MP is the industry standard for graphic and nameplate attachment
• 5.0 mil acrylic adhesive performs even when exposed to humidity and hot/cold cycles
• High adhesive shear strength helps resist slippage and edge lifting on HSE plastics
• Provides some repositionability on plastics for precise alignment of graphics and parts
• 58# PCK liner adds stability for storage and die-cutting

• Color: Transparent
• Package Quantity: 1 RLS
• Width: 24 in
