3M Electrically Conductive Single-Sided Tape 1020BC-25, Black, 100mm x 10m, 8 Rolls per Case
Hisco #:7100313406-31180
MFG #:7100313406
Item must be ordered in multiples of 1
| Quantity | Price | Save |
|---|---|---|
| 1 | 77.59 | |
| 8 | 75.96 | Save |
| 24 | 74.41 | Save |
The 3M 7100313406 is an XYZ-axis electrically conductive pressure sensitive adhesive (CPSA) tape that helps enable devices to meet electromagnetic compatibility requirements. It consists of a conductive black copper foil backing, a conductive acrylic adhesive layer and a polyester (PET) release liner. This black copper foil tape provides excellent XYZ-axis-based conductivity, reliable contacts to small-size grounding areas and excellent EMI shielding and electrical reliability over time. The thin profile makes it a great option for applications with less Z-space. It offers high adhesion and good grounding performance to many surface types.
3M 7100313406 Features:- Improved workability due to stiffer copper
- Low electrical resistance
- Excellent EMI shielding performance
- Excellent conformability and quick bonding
- Good handling
- Halogen free* and RoHS compliant**
- Brand: 3M
- Product Type: Electrically Conductive Tape
- Series: 1020BC
- Adhesion Strength:1300 gf/in
- Adhesive Type: Acrylic
- Backing: Copper Foil
- Electrical Resistance: XY-axis 0.015 Ω, Z-axis 0.1 Ω
- Liner Material: PET
- Maximum Operating Temperature: 250 Degree Fahrenheit
- Minimum Operating Temperature: -40 Degree Fahrenheit
- Length: 10m
- Width: 100mm
- Product Color: Black
- Package Quantity: 8 Rolls per Case
Product Description
The 3M 7100313406 is an XYZ-axis electrically conductive pressure sensitive adhesive (CPSA) tape that helps enable devices to meet electromagnetic compatibility requirements. It consists of a conductive black copper foil backing, a conductive acrylic adhesive layer and a polyester (PET) release liner. This black copper foil tape provides excellent XYZ-axis-based conductivity, reliable contacts to small-size grounding areas and excellent EMI shielding and electrical reliability over time. The thin profile makes it a great option for applications with less Z-space. It offers high adhesion and good grounding performance to many surface types.
3M 7100313406 Features:- Improved workability due to stiffer copper
- Low electrical resistance
- Excellent EMI shielding performance
- Excellent conformability and quick bonding
- Good handling
- Halogen free* and RoHS compliant**
- Brand: 3M
- Product Type: Electrically Conductive Tape
- Series: 1020BC
- Adhesion Strength:1300 gf/in
- Adhesive Type: Acrylic
- Backing: Copper Foil
- Electrical Resistance: XY-axis 0.015 Ω, Z-axis 0.1 Ω
- Liner Material: PET
- Maximum Operating Temperature: 250 Degree Fahrenheit
- Minimum Operating Temperature: -40 Degree Fahrenheit
- Length: 10m
- Width: 100mm
- Product Color: Black
- Package Quantity: 8 Rolls per Case
