3 Series Force Gauge, 1 lbF / 0.5 kgF / 5 N

The Mark-10 M3-1 Series 3 Basic Digital Force Gauge is designed for reliable tension and compression force testing in manufacturing, quality control, assembly verification, and laboratory applications. With a capacity of 1 lbF (5 N), the M3-1 provides straightforward force measurement functionality in a compact, lightweight design.The M3-1 features a 2,000 Hz sampling rate and ±0.3% full-scale accuracy, helping users achieve dependable results across a wide range of force testing applications. A backlit graphic LCD displays force readings clearly, while intuitive menu navigation provides access to key settings and measurement functions.Compatible with Mark-10 test stands, grips, and software, the M3-1 can be used as a handheld instrument or integrated into a more structured force testing setup.The Mark-10 M3-1 is intended for users who need an efficient and cost-effective solution for compression and tension testing. The 2,000 Hz sampling rate provides responsive force measurement performance, while programmable set points support pass/fail testing procedures commonly used in production and inspection environments.The gauge also includes a live load bar graph with set point markers, allowing operators to monitor applied force visually during testing. Peak readings remain visible on-screen, helping users capture and review maximum force values without additional equipment.Its reversible aluminum housing provides flexibility for both handheld operation and mounting to a compatible force test stand.The M3-1 digital force gauge includes USB connectivity for transferring force measurement data to a computer. The included MESUR Lite software allows users to collect, organize, and export continuous or single-point test data directly to Microsoft Excel.This capability supports documentation, traceability, and reporting requirements in quality control and product testing applications.The Mark-10 M3-1 Series 3 Basic Digital Force Gauge is compatible with Mark-10 test stands, grips, fixtures, and software systems.Its compact size, straightforward operation, and compatibility with professional testing equipment make the M3-1 a practical choice for users seeking a dependable digital force gauge, force measurement instrument, tension and compression tester, or quality control testing equipment.

• Capacity: 1 lbF / 0.5 kgF / 5 N
• Accuracy: ±0.3% of full scale
• Sampling Rate: 2,000 Hz
• Measurement Type: Tension and compression force measurement
• Display: Backlit graphic LCD with live load bar graph
• Data Output: USB output for continuous or individual data points
• Set Points: Programmable pass/fail set points with visual indicators
• Units of Measurement: lbF, gF, kgF, and N (depending on model)
• Communication Speed: USB configurable up to 115,200 baud
• Overload Protection: 200% of full scale
• Power Source: AC adapter or rechargeable battery
• Battery Life: Up to 7 hours with backlight on; up to 24 hours with backlight off
• Weight: 0.7 lb (0.3 kg)
• Compliance: CE and UKCA
• Country of Origin: USA
• Warranty: 3 years
