4 Series Force Gauge, 1 lbF / 16 ozF / 500 gF / 0.5 kgF / 5 N / 5000 mN

The Mark-10 M4-1 Series 4 Performance Digital Force Gauge is designed for tension and compression force testing across manufacturing, quality control, laboratory, product development, and inspection applications. With a capacity of 1 lbF (5 N), the M4-1 combines reliable force measurement performance with straightforward operation and broad compatibility with Mark-10 testing equipment.The M4-1 features a 3,000 Hz sampling rate, ±0.2% full-scale accuracy, and a resolution of 1/2000, helping users capture force measurements accurately across a wide range of testing conditions. A large backlit graphic display provides clear visibility of readings, while intuitive menu navigation allows quick access to key functions and configuration settings.For data collection and reporting, the gauge includes onboard memory, statistical analysis functions, multiple communication outputs, and MESUR Lite software for exporting measurement data to Excel.The Mark-10 M4-1 is well suited for organizations that need dependable force measurement without the complexity of advanced automation features. Built-in memory stores up to 50 readings, while onboard statistical calculations provide quick insight into testing performance through minimum, maximum, mean, and standard deviation values.A live load bar graph with programmable set point markers offers visual feedback during testing, making the M4-1 useful for pass/fail inspections, production testing, and general quality assurance processes.The gauge's reversible aluminum housing supports both handheld operation and mounting to a compatible test stand for more controlled testing procedures.The M4-1 digital force gauge integrates easily into existing force testing workflows through multiple output options.Included MESUR Lite software enables users to collect continuous or single-point force data and export results directly to Microsoft Excel for reporting and further analysis.The Mark-10 M4-1 Series 4 Performance Digital Force Gauge is directly compatible with Mark-10 test stands, grips, fixtures, and software systems.Its combination of measurement accuracy, versatile connectivity, and compatibility with professional testing equipment makes the M4-1 a practical solution for users seeking a reliable digital force gauge, force testing equipment, tension and compression tester, or industrial force measurement instrument.

• Capacity: 1 lbF / 16 ozF / 500 gF / 0.5 kgF / 5 N
• Accuracy: ±0.2% of full scale
• Resolution: 1/2000 of full scale
• Sampling Rate: 3,000 Hz
• Data Memory: Stores up to 50 readings
• Statistical Functions: Minimum, maximum, mean, and standard deviation calculations
• Measurement Type: Tension and compression force measurement
• Display: Backlit graphic LCD with live load bar graph
• Set Points: Programmable pass/fail set points with alarms and outputs
• Connectivity: USB, RS-232, Mitutoyo Digimatic, and analog outputs
• Communication Speed: USB/RS-232 configurable up to 115,200 baud
• Analog Output: ±1 VDC, ±0.25% of full scale at capacity
• Units of Measurement: lbF, ozF, gF, kgF, N, kN, and mN (model dependent)
• Overload Protection: 200% of full scale
• Power Options: AC adapter or rechargeable battery
• Battery Life: Up to 7 hours with backlight on; up to 24 hours with backlight off
• Compliance: CE and UKCA
• Country of Origin: USA
• Warranty: 3 years
