7 Series Force Gauge, 1 lbF / 16 ozF / 500 gF / 0.5 kgF / 5 N / 5000 mN
Hisco #:10333212
MFG #:M7-1
Item must be ordered in multiples of 1
| Quantity | Price | Save |
|---|---|---|
| 1 | 2100.00 | |
| 3 | 1997.72 | Save |
The Mark-10 M7-1 Series 7 Professional Digital Force Gauge is designed for demanding tension and compression measurement applications requiring high accuracy, rapid sampling, and advanced data collection capabilities. With a capacity of 1 lbF (5 N), the M7-1 delivers ±0.1% full-scale accuracy and an industry-leading 14,000 Hz sampling rate, making it well suited for fast-event force testing, break testing, materials testing, and quality control environments.As part of the Series 7 lineup, the M7-1 expands on the functionality of the Series 5 force gauges with advanced features including continuous high-speed data capture, programmable automation functions, break detection, and first/second peak detection. Internal memory supports up to 5,000 readings, which can be downloaded to a PC for analysis and reporting.The gauge is compatible with Mark-10 test stands, grips, and fixtures, enabling a wide range of force measurement applications including tensile testing, compression testing, break testing, dynamic load holding, and computer-controlled testing systems.MESUR Lite software is included for data acquisition and analysis. Continuous or single-point measurements can be recorded and exported directly to Excel for further evaluation and documentation.The Mark-10 M7-1 is built for applications where capturing short-duration force events is critical. Its 14,000 Hz sampling rate helps ensure transient peaks and break forces are measured with a high degree of confidence.Built-in automation features reduce operator intervention by enabling automatic data output, storage, and zeroing after specific testing events, including break detection, averaging sequences, and peak measurements. Programmable footswitch commands and configurable set points further support repeatable testing procedures.The M7-1 digital force gauge offers multiple communication options for integration into laboratory, manufacturing, and quality assurance workflows.Included MESUR Lite software allows users to capture continuous or single-point force data, organize results, and export directly to Microsoft Excel for analysis and reporting.
Mark-10 M7-1 Features:- Capacity: 1 lbF / 16 ozF / 500 gF / 0.5 kgF / 5 N
- Accuracy: ±0.1% of full scale
- Sampling Rate: 14,000 Hz
- Data Output Rate: Up to 500 Hz
- Internal Memory: Up to 5,000 readings or continuous data points
- Continuous Data Capture: Up to 14,000 Hz, downloadable to PC
- Measurement Modes: Tension and compression force measurement
- Peak Detection: 1st peak and 2nd peak detection
- Break Testing Functions: Automatic detection, data storage, output, and zeroing
- Units of Measurement: lbF, ozF, gF, kgF, N, kN, mN (model dependent), coefficient of friction, and user-defined units
- Connectivity: USB, RS-232, Mitutoyo Digimatic, analog output, programmable I/O
- Computer Integration: Gauge Control Language 2 support for full PC control
- Programmable Features: Set points, footswitch commands, password protection, averaging mode, and external trigger mode
- Safe Overload Protection: 200% of full scale
- Power Options: AC operation or rechargeable battery
- Battery Life: Up to 7 hours with backlight on; up to 24 hours with backlight off
- Compliance: CE and UKCA
- Country of Origin: USA
- Warranty: 3 years
Product Description
The Mark-10 M7-1 Series 7 Professional Digital Force Gauge is designed for demanding tension and compression measurement applications requiring high accuracy, rapid sampling, and advanced data collection capabilities. With a capacity of 1 lbF (5 N), the M7-1 delivers ±0.1% full-scale accuracy and an industry-leading 14,000 Hz sampling rate, making it well suited for fast-event force testing, break testing, materials testing, and quality control environments.As part of the Series 7 lineup, the M7-1 expands on the functionality of the Series 5 force gauges with advanced features including continuous high-speed data capture, programmable automation functions, break detection, and first/second peak detection. Internal memory supports up to 5,000 readings, which can be downloaded to a PC for analysis and reporting.The gauge is compatible with Mark-10 test stands, grips, and fixtures, enabling a wide range of force measurement applications including tensile testing, compression testing, break testing, dynamic load holding, and computer-controlled testing systems.MESUR Lite software is included for data acquisition and analysis. Continuous or single-point measurements can be recorded and exported directly to Excel for further evaluation and documentation.The Mark-10 M7-1 is built for applications where capturing short-duration force events is critical. Its 14,000 Hz sampling rate helps ensure transient peaks and break forces are measured with a high degree of confidence.Built-in automation features reduce operator intervention by enabling automatic data output, storage, and zeroing after specific testing events, including break detection, averaging sequences, and peak measurements. Programmable footswitch commands and configurable set points further support repeatable testing procedures.The M7-1 digital force gauge offers multiple communication options for integration into laboratory, manufacturing, and quality assurance workflows.Included MESUR Lite software allows users to capture continuous or single-point force data, organize results, and export directly to Microsoft Excel for analysis and reporting.
Mark-10 M7-1 Features:- Capacity: 1 lbF / 16 ozF / 500 gF / 0.5 kgF / 5 N
- Accuracy: ±0.1% of full scale
- Sampling Rate: 14,000 Hz
- Data Output Rate: Up to 500 Hz
- Internal Memory: Up to 5,000 readings or continuous data points
- Continuous Data Capture: Up to 14,000 Hz, downloadable to PC
- Measurement Modes: Tension and compression force measurement
- Peak Detection: 1st peak and 2nd peak detection
- Break Testing Functions: Automatic detection, data storage, output, and zeroing
- Units of Measurement: lbF, ozF, gF, kgF, N, kN, mN (model dependent), coefficient of friction, and user-defined units
- Connectivity: USB, RS-232, Mitutoyo Digimatic, analog output, programmable I/O
- Computer Integration: Gauge Control Language 2 support for full PC control
- Programmable Features: Set points, footswitch commands, password protection, averaging mode, and external trigger mode
- Safe Overload Protection: 200% of full scale
- Power Options: AC operation or rechargeable battery
- Battery Life: Up to 7 hours with backlight on; up to 24 hours with backlight off
- Compliance: CE and UKCA
- Country of Origin: USA
- Warranty: 3 years
