Cutters, Blade Length .11" x .155" Transverse End
Hisco #:7173E-18168
MFG #:7173E
Item must be ordered in multiples of 30
| Quantity | Price | Save |
|---|---|---|
| 90 | 162.50 | Save |
The Excelta 7173E is a Lazer Line® tapered, transverse laser flush cutter with a cutting capacity of .001" - .020". It is made of carbon tool steel with induction hardened cutting blades to RHC 63-65. The overall length is 6" . The CNC machining allows the joint surfaces to be perfect to allow for long life. This 6" tool has a 40° angled tip with a set-screw to prevent over-travel while prolonging the life of the tool. The Anti-Static grips are soft cushioned foam and have a surface resistivity of 10¹⁰ ohms/sq.The dual leaf springs provide smooth action.
Excelta 7173E Features:- Made of cargon tool steel
- Offers anti-static grips
- Utilizes dual leaf springs
- Precision: 5 Star
- Surface Resistivity: 10¹⁰ ohms/sq
- Shape: Transverse End
- Brand: TealShield™/Lazer Line®
- Material: Carbon
- Tip Size: .11" x .155" (2.75mm x 3.88mm)
- Body Height: .25" (6.25mm)
- Tip Angle: 90°
- Width at Joint: 0.42" (10.5mm)
- Height at Joint: .25"
- Cutting Edge Length: .22"
- Handle Type: Long Cushioned Grips
- Type of Cut: Lazer Flush
- Maximum Cut Capacity (Inches): .001 - .020"
- Maximum Cut Capacity (mm): .03 - .5 mm
- Maximum Cut Capacity (AWG): 50 - 24 AWG
- Overall Length: 6" (150mm)
Product Description
The Excelta 7173E is a Lazer Line® tapered, transverse laser flush cutter with a cutting capacity of .001" - .020". It is made of carbon tool steel with induction hardened cutting blades to RHC 63-65. The overall length is 6" . The CNC machining allows the joint surfaces to be perfect to allow for long life. This 6" tool has a 40° angled tip with a set-screw to prevent over-travel while prolonging the life of the tool. The Anti-Static grips are soft cushioned foam and have a surface resistivity of 10¹⁰ ohms/sq.The dual leaf springs provide smooth action.
Excelta 7173E Features:- Made of cargon tool steel
- Offers anti-static grips
- Utilizes dual leaf springs
- Precision: 5 Star
- Surface Resistivity: 10¹⁰ ohms/sq
- Shape: Transverse End
- Brand: TealShield™/Lazer Line®
- Material: Carbon
- Tip Size: .11" x .155" (2.75mm x 3.88mm)
- Body Height: .25" (6.25mm)
- Tip Angle: 90°
- Width at Joint: 0.42" (10.5mm)
- Height at Joint: .25"
- Cutting Edge Length: .22"
- Handle Type: Long Cushioned Grips
- Type of Cut: Lazer Flush
- Maximum Cut Capacity (Inches): .001 - .020"
- Maximum Cut Capacity (mm): .03 - .5 mm
- Maximum Cut Capacity (AWG): 50 - 24 AWG
- Overall Length: 6" (150mm)
